Guangdong JSWAY CNC Machine Tool Co., Ltd. since 2004.
For a variety of machining needs, including high-speed, heavy-duty, and 5-axis machining, JSWAY vertical machining centers delivers lasting performance. Due to a vibration-dampening Mitsubichi/Fanuc cast iron base and large precision spindle bearings, we offer shops increased rigidity while sustaining higher load capacities. Every vertical machining center features fully-equipped Fanuc controls for maximum machining capabilities.
Machine parameter
PARAMETER | |||
| MODEL | UNIT | JDL1065 | |
CONTROLLER | NC | SET | MITSUBICHI/FANUC |
| TOTAL AXIS | AXIS | 3 | |
TABLE | TABLE SIZE | MM | 1050*500 |
| TABLE LOAD | KG | 700 | |
| T-SLOT | MM | 5-18*90 | |
TRAVEL | X AXIS | MM | 800 |
| Y AXIS | MM | 500 | |
| Z AXIS | MM | 500 | |
SPINDLE | SPINDLE TAPPER | MM | BT40 |
| MAX.SPINDLE SPEED | RPM/MIN | 8000/10000 | |
| SPINDLE DRIVEN TYPE | TYPE | belt type | |
| SPINDLE CENTER TO MACHINE SPINE | MM | 525 | |
| SPINDLE END FACE TO TABLE | MM | 135-635 | |
GUIDE RAIL | X/Y/Z AXIS BALL SCREW | MM | 4010/4010/4010 |
| X/Y/Z AXIS GUIDE RAIL | BOX RAIL | ||
MOTOR | X/Y/Z AXIS MOTOR CONNECT TYPE | TYPE | direct |
| SPINDLE MOTOR | KW | 7.5 | |
| X/Y/Z AXIS SERVO MOTOR | KW | 3/3/3 | |
| COOLANT PUMP MOTOR | W | 750W | |
FEEDING RATE | X/Y/Z WORKING RATE | M/MIN | 10/10/10 |
| X/Y/Z RAPID SPEED | M/MIN | 15/15/15 | |
POWER/AIR PRESSURE | AIR PRESSURE | KG/CM² | 6kg/cm² |
| POWER SUPPLY | kva | 20kva | |
ACCURACY | POSITIONING ACCURACY | MM | ±0.005/300 |
| REPOSITIONING ACCURACY | MM | ±0.005/300 | |
SPEC | NET WEIGHT | T | 5 |
| DEMENSION | MM | 2500*2400*2700 | |
High Rigidity Structural Design
1. Adopted consistent production process, wear resistance, are the best for heavy cutting.
2. The rigid body construction makes for uncompromising precision and rigidity.
3. Boxway design on 3 axis is suitable for heavy cutting.
4. The wide span 500 mm Y-axis with rigid dual-wall saddle design fully supports table movement.
5. No counter weight on Z-axis provides the best dynamic accuracy.
1. Full enclosure exterior (including top cover).
2. Convertible side window for convenient chip removal.
3. Aesthetic rear cover design.
4. Smooth chip removal.
5. Dual chip augers combined with chip conveyor for fast chip disposal (opt.)
