VMC Vertical Machining Center Supplier Vertical CNC Tapping Center JDT640

    oops...!

    no product data.

    Go to homepage
    Price term
    EXW FOB CIF
    Payment term
    T/T L/C30\% deposite
    MOQ
    1 set
    Nearest port
    shenzhen guangzhou zhongshan

    A VMC Vertical machining center is a cutting-edge industrial tool designed to revolutionize precision machining processes. This cutting-edge equipment employs advanced computer numerical control (CNC) technology, allowing for exceptional accuracy and efficiency in fabricating complex components. The VMC Vertical Machining Center boasts a robust vertical spindle that smoothly moves along multiple axes, facilitating the rapid removal of material with unparalleled precision. The machine's versatile worktable can accommodate various sized workpieces, guaranteeing impeccable results no matter the project scale. Equipped with state-of-the-art cooling systems, these centers prevent overheating during prolonged operations while maintaining optimal performance levels. With its user-friendly interface and intuitive controls, operators can effortlessly program intricate designs and execute them flawlessly using this powerful machinery. Its capability to handle both large-scale industrial production and intricate prototyping makes the VMC Vertical Machining Center an indispensable asset across numerous sectors from aerospace engineering to automotive manufacturing.

    product-China Supplier new version vertical cnc tapping center JDT640-JSWAY-img
    product-JSWAY-img



    Machine parameter



    PARAMETER

    MODELUNITJD640JDT640


    CONTROLLER

    NCSETMITSUBICHI E80MITSUBICHI M80/FANUC
    TOTAL AXIS AXIS33



    TABLE

    TABLE SIZEMM700*420700*420
    TABLE LOADKG300300
    T-SLOTMM3-14*1253-14*125



    TRAVEL

    X AXISMM600600
    Y AXISMM400400
    Z AXISMM300300





    SPINDLE

    SPINDLE TAPPERMMBT30/Φ100BT30/Φ100
    MAX.SPINDLE SPEEDRPM/MIN24000/3000015000/20000
    SPINDLE DRIVEN TYPETYPEelectrical spindledirect
    SPINDLE CENTER TO MACHINE SPINEMM500500
    SPINDLE END FACE TO TABLEMM150-450150-450


    GUIDE RAIL

    X/Y/Z AXIS BALL SCREWMM2808/2808/32083216/3216/3216
    X/Y/Z AXIS  GUIDE RAIL
    linear guide raillinear guide rail




    MOTOR

    X/Y/Z AXIS MOTOR CONNECT TYPETYPEdirectdirect
    SPINDLE MOTORKW5.55.5
    X/Y/Z AXIS SERVO MOTOR KW1.5/1.5/3.01.5/1.5/3.0
    COOLANT PUMP MOTORW750W*2750W*2


    FEEDING RATE

    X/Y/Z WORKING RATEM/MIN10/10/1010/10/10
    X/Y/Z RAPID SPEEDM/MIN24/24/2460/60/48


    POWER/AIR PRESSURE

    AIR PRESSUREKG/CM²6kg/cm²6kg/cm²
    POWER SUPPLYkva15kva15kva


    ACCURACY

    POSITIONING ACCURACYMM±0.003/300±0.005/300
    REPOSITIONING ACCURACYMM±0.003/300±0.005/300


    SPEC

    NET WEIGHTT  3.23.2
    DEMENSIONMM2000*2000*21002000*2000*2100



    Standard Accessory



    • Water tank and chips filter

    • Auto lubrication system

    • File transfer software and cable

    • Spindle oil cooler

    • Hand wheel

    • Transformer

    • 3 color warning lamp

    • Tool box

    • Full cover

    • Anchor bolt

    • Double working lamp

    • Turret(16tools)

    • Air blow gun

    • Tool box

    • Manual

    • Cabinet heat exchange



    product-JSWAY-tapping machine-img
    product-tapping machine-JSWAY-img
    product-JSWAY-img
